VS-UV and SWIR Series
See Beyond The Visible Range
VS-UV and SWIR Series
Specially designed for visible and infrared wavelengths
Machine Vision design
Image taken with Visible Light and normal Lens
Image taken with IR Light and IR Lens
| Modelname | Opt. Mag. | WD(mm) | Working F/# | FOV (VxHmm) | TV Distortion | Sensor Size | Remarks |
|---|---|---|---|---|---|---|---|
| VS-MC00303NS-UV | 0.03x～0.3x | 520.1～38.1 | 4.8~16.1～ 6.4~21.3 | 160x213.3～ 16x21.3(1/2") | ～-0.01% | 2/3" | More Info |
| VS-MC0510S-UV | 0.5x～1.0x | 134.1～88.1 | 4.8～6.4 | 9.6x12.8～ 4.8x6.4(1/2") | -0.0007%～ -0.0085% | 1/2" | More Info |
| VS-MC2-65UV365 | 2.0x | 64 | 9.4 | 2.4x3.2 (1/2") | 0.001 | 1/2" | More Info |
| VS-MC3-65UV365 | 3.0x | 65.3 | 9.27 | 1.6x2.1 (1/2") | 0.001 | 1/2" | More Info |
| VS-MC01303IR | 0.13x～0.3x | 176.3～78.2 | 4.00～4.60 | 50.4x67.2～ 22.0x29.3(2/3") | ～0.1% | Φ22 | More Info |
| Modelname | f (mm) | FNO | VxH | Max. Sensor Size | MOD with out extension ring(mm) | Remarks |
|---|---|---|---|---|---|---|
| VS-0614V-IR | 6 | 1.4 - © | 42.3x54.6(1/2") | 1/2" | 200-∞ | More Info |
| VS-0813V-IR | 8 | 1.3 - © | 44.6x57.3(2/3") | 2/3" | 200-∞ | More Info |
| VS-1214V-IR | 12 | 1.4 - © | 21.9x28.9(1/2") | 1/2" | 300-∞ | More Info |
| VS-1614V-IR | 16 | 1.4 - © | 22.8x30.1(2/3") | 2/3" | 400-∞ | More Info |
| VS-2514V-IR | 25 | 1.4 - © | 14.9x19.8(2/3") | 1" | 500-∞ | More Info |
| VS-3518V-IR | 35 | 1.8 - © | 10.8x14.4(2/3") | 2/3" | 300-∞ | More Info |
| VS-5018V-IR | 50 | 1.8 - © | 7.9x10.5(2/3") | 2/3" | 1000-∞ | More Info |
