Direct Ring Light V2DR-Si90B-AOI
V2DR-Si90B-AOI is a Direct Ring Light with surface mount LEDs designed for machine vision application commonly used for AOI application. It has an Outer Diameter (OD) of 90 mm and Inner Diameter (ID) of 50mm, illuminating an area of 82 mm in diameter. It comes in 4 spectrum options, Red, Blue, Green and White.
Ordering Information
Models with Resistors : V2DR-Si90B-AOI- G12/B12/W12/R24/G/B/W
Models without Resistors : V2DR-Si90B-AOI- G12/B12/W12/R24/G/B/W-O
Example : Model for Blue version with no resistor : “V2DR-Si90B-AOI-B-O”, Model for Green version with resistor “V2DR-Si90B-AOI-G”
