Line Light with Cylindrical Lens V2LN Series is focused by a cylindrical lens to increase full intensity at the object or inspection area. UV models are available for this series.

Illumination Structure:
This line light is focused by a cylinder lens to achieve a focused beam.

V2HLN-Si150 is super bright lighting; avoid staring at exposure lighting when operating. Useful for applications that need to be visible at long distances and is recommended as strobe lighting to perform high-brightness lighting with a longer life span.

Ordering Information

Models with Resistors :        V2HLN-Si150-R24/G/B/W

Models without Resistors :  V2HLN-Si150-R24/G/B/W-O

Example : Model for White version with no resistor : “V2HLN-Si150-W-O”,   Model for Green version with resistor “V2HLN-Si150-G”
