The V2HLV series is a high powered spot lights that are compatible with machine micro lenses. Collimated optics and light guides to produce maximum illumination which enables long working distance. The V2HLV is small and light weight for easy handling. Stable illumination when used with a dedicated constant current power source. UV and SWIR models are available for this series.

Illumination Structure:
Specially designed condenser lens and rod lens are combined to emit highly uniform, high luminosity condensed light.

This product has UV Lighting is ideal to activate the fluorescent object. This product has UV Lighting is ideal to activate the fluorescent object. Vital Vision provides more than 10 series of UV lighting with wavelength 375nm and 400nm. This product come with 6.0 Watt and 0.5 Ampere.

Ordering Information

With Resistor version :       V2HLV-Si27N2-UV

Without Resistor version : V2HLV-Si27N2-UV-O

Example : Model for UV version with no resistor : “V2HLV-Si27N2-UV-O“,   Model for UV version with resistor “V2HLV-Si27N2-UV”
