Alvium 1800 U-511M

Versatile USB camera with IMX547 CMOS sensor

Main  >  Product  >  Area Scan camera  >  USB3 Cameras > Allied Vision USB3 Cameras > Alvium 1800 U-511M

Alvium 1800 U-511M

Alvium 1800 U-511 with Sony IMX547 runs 66.0 frames per second at 5.1 MP resolution.

Alvium 1800 U is your entry into high-performance imaging with ALVIUM® Technology for industrial applications. Equipped with the newest generation of sensors, these small and lightweight cameras deliver high image quality and frame rates at the best price-performance ratio. With its USB3 Vision compliant interface and industrial-grade hardware, it is your workhorse for different machine vision applications whether it is on a PC-based or an embedded system.



  • IMX547 CMOS sensor
  • ALVIUM image processing
  • USB3 Vision
  • Various hardware options
Model Alvium 1800 U-511M
InterfaceUSB3 Vision
Resolution2464 (H) × 2064 (V)
SensorSony IMX547
Sensor typeCMOS
Shutter modeGlobal shutter
Sensor sizeType 1/1.8
Pixel size2.74 μm × 2.74 μm
Max. frame rate at full resolution66 fps at 375 MByte/s, Mono8
ADC12 Bit
Image buffer (RAM)256 KB
Non-volatile memory (Flash)1024 KB
Bit depthMax. 12 Bit
Monochrome pixel formatsMono8, Mono10, Mono10p, Mono12, Mono12p
TTL I/Os4 programmable GPIOs
Operating temperature+5 °C to +65 °C (housing)
Power requirements (DC)Power over USB 3.1 Gen 1 | External power 5.0 V
Power consumptionUSB power: 3.2 W (typical) | Ext. power: 3.4 W (typical)
Regulations2014/30/EU; 2011/65/EU, incl. amendment 2015/863/EU Regulations (RoHS); FCC Class B digital device; CAN ICES-003 (B) /
NMB-3 (B

Configure Your Camera

Closed Housing

ClosedHousingC-Mount

1800 U-511M     C-Mount

Order code : V215931

ClosedHousingCS-Mount

1800 U-511M     CS-Mount

Order code : V215932

ClosedHousingS-Mount

1800 U-511M     S-Mount

Order code : V215933

ClosedHousingC-Mount90°

1800 U-511M     C-Mount

Order code : V215937

ClosedHousingCS-Mount90°

1800 U-511M     CS-Mount

Order code : V215938

ClosedHousingS-Mount90°

1800 U-511M     S-Mount

Order code : V215939

Open Housing

Open Housing

1800 U-511M     C-Mount

Order code :  V215943

OpenHousingCS-MountStandard

1800 U-511M     CS-Mount

Order code :  V215944

OpenHousingS-MountStandard

1800 U-511M     S-Mount

Order code :  V215945

OpenHousingC-Mount90°

1800 U-511M     C-Mount

Order code : V215949

OpenHousingCS-Mount90

1800 U-511M     CS-Mount

Order code : V215950

OpenHousingS-Mount90°

1800 U-511M     S-Mount

Order code : V215951

Bareboard Housing

BareBoard

1800 U-511M

Order code : V215927

BareBoard90°

1800 U-511M

Order code : V215929
