V2DR-i132LA3-IP55 is a Low Angle  Ring Light with through hole mount  LEDs designed for machine vision application. It has 8  independent sections of light with separate controls, design as lighting ideal for shape from shading 3D application. It has an Outer Diameter (OD) of 140 mm and Inner Diameter (ID) of 85 mm and an illumination area of 117 mm in diameter.  This product has IP lighting which help to protect the lighting against contact and infiltration of water and dirt which classified by degree of protecion.

Ordering Information

Models with Resistors :         V2DR-i132LA3-IP65-W

Models without Resistors :  V2DR-i132LA3-IP65-W-O

Example : Model for White  version with no resistor : “V2DR-i132LA3-IP65-W-O”,   Model for White  version with resistor “V2DR-i132LA3-IP65-W”
