VS-TC08-220CO
- Compact size and light weight
- Wide range of WD from 40mm～340mm
- Variety of magnifications 0.5x～10x : 1.5x / 3.0x / 5.0x also available
- Built-in Co-axial models
| Model | VS-TC08-220CO | |
|---|---|---|
| Optical mag. | x 0.8 ± 5 % | |
| 2/3" | - | |
| FOV (VxH) | 1/2" | 6.0 × 8.0 mm |
| 1/3" | 4.5 x 6.0 mm | |
| WD | 122.5 mm ± 3 | |
| O/I (Object & Imager distance) | 211.8 mm | |
| Working F/# | 18.0 | |
| NA | 0.022 | |
| DOF at PCoC φ0.04mm | 2.3 mm | |
| TV distortion (max.) | 0.10 % | |
| Relative illuminance(Y=4) | 90 % | |
| Wavelength | Visible | |
| Camera mount | C-mount | |
| Flange back | 17.526mm | |
| Sensor size (max.) | 1/2" | |
| Co-axial prism | Built-in | |
| Weight (approx.) | 46 g | |
| Dimension | φ31 (MAX) x L= 71.8 mm |
