VS-TCT Series
Main > Product > Machine Vision Lenses >Telecentric Lens > VS-TCT Series
VS-TCT Series
Supports high resolution 1.67µm, 10 megapixel camera
Designed for machine vision applications require precision and accuracy
Low distortion
Straight and Co-axial models available
| Modelname | Mag. | WD(mm) | Fno | NA | Co-ax lighting prism | Remarks |
|---|---|---|---|---|---|---|
| VS-TCT05-65/S | 0.5 | 65.7 | 4.5 | 0.056 | - | VS-TCT05-65/S |
| VS-TCT05-65CO/S | 0.5 | 65.7 | 4.5 | 0.056 | Built-in | VS-TCT05-65CO/S |
| VS-TCT08-65/S | 0.8 | 65.1 | 4.5 | 0.089 | - | VS-TCT08-65/S |
| VS-TCT08-65CO/S | 0.8 | 65.1 | 4.5 | 0.089 | Built-in | VS-TCT08-65CO/S |
| VS-TCT1-65/S | 1 | 66 | 4.5 | 0.111 | - | VS-TCT1-65/S |
| VS-TCT1-65CO/S | 1 | 66 | 4.5 | 0.111 | Built-in | VS-TCT1-65CO/S |
