Direct Ring Light V2DR-i50A

V2DR-i50A is a Direct Ring light designed for machine vision application. It has an Outer Diameter (OD) of 49mm and Inner Diameter (ID) of 23mm. Build with through hole LEDs It comes in 5 spectrum options, Red , NIR,  Blue, Green and White.

Ordering Information

With Resistor version :         V2DR-i50A-SR/SR24/IR/IR24/G/B/W
Without Resistor version :  V2DR-i50A-SR/SR24/IR/IR24/G/B/W-O



Example : Model for Blue version with no resistor : “V2DR-i50A-B-O”,   Model for NIR version with resistor “V2DR-i50A-IR”
