Toshiba Teli Surface Flaw Detection Scope SFD240305A
Toshiba Teli Surface Flaw Detection Scope SFD240305A utilizes Toshiba’s innovative “OneShotBRDF™” technology to detect surface flaws in a single shot, making it ideal for visualizing challenging microdefects on flat surfaces.
Key features
- High-Speed Inspection: Uses a multi-wavelength coaxial aperture filter with scattered light discrimination for rapid and accurate flaw detection.
- Enhanced Visibility: Highlights hard-to-identify scratches in images using distinct colors for easy differentiation.
- High-Resolution Imaging: Equipped with a BU2409MCF high-resolution USB camera, providing a seamless connection to your PC for efficient inspections.
Benefits
- Shows the base material and flaws/defects in different colors without the need for post-image processing
- No need for skilled labor for inspection
- Quality stabilization
- Reduction in inspection time
- Highly compatible with AI-based post-processing
| Model Name | SFD240305A |
|---|---|
| Item | Specifications |
| Measurement view (for reference only) | Ø40mm |
| Minimum detectable flaw size (for reference only) | Several tens of micrometers |
| Item | Specifications |
| Camera | BU2409MCF (Color model) |
| Image sensor | IMX540 (Sony Corp.) |
| Resolution | 24.5 MP (5,328 x 4,608 pix) |
| Pixel size | 2.74μm x 2.74μm |
| Interface | USB 5Gbps (USB3.1 Gen1) |
Capable of identifying micro defects that have previously been difficult to detect
- Shows the base material and flaws/defects in different colors without the need for post-image processing
- No need for skilled labor for inspection
- Quality stabilization
- Reduction in inspection time
- Highly compatible with AI-based post-processing
