VS-MC50H1
The VS-MC50H1 is a high-resolution ruggedized fixed focal length lens meticulously crafted for 1″ format cameras. Boasting a focal length of 50mm and a minimum object distance (M.O.D) of 500mm, this lens is engineered to deliver exceptional clarity and detail. With a versatile aperture range from F1.4 to F8, it adapts seamlessly to diverse lighting conditions, ensuring optimal image quality. The C-mount design adds flexibility and compatibility to the lens, making it suitable for a range of imaging setups. Whether capturing intricate details or expansive scenes, the VS-MC50H1 combines high resolution and rugged durability, making it a reliable choice for demanding applications in the 1″ format realm.
| Model | VS-MC50H1 |
|---|---|
| Focal Length | 50mm |
| Maximum Aperture | 1: 1.8 |
| Angle of View | 12.8°× 12.8°(Diagonal:18.1) |
| MOD | 500 mm |
| TV Distortion | -0.01 % |
| Operation | Manual |
| Wavelength | Visible |
| Camera mount | C-mount |
| Flange Back | 17.526 mm |
| Sensor Size | 1" |
| Filter Thread | M=40.5 P=0.5 |
| Weight (approx.) | 94 g |
| Dimension | φ44(max.) × L = 44.5 mm |
