50x M Plan Apo
- Sufficient working distance from 13 to 41 mm
- Infinity corrected
- Consistent 95 mm shoulder to object distance
- NA from 0.055 to 0.6 Standard thread adapter required for mounting
Parameter | Value |
---|---|
Numerical Aperture | 0.55 |
Working Distance (mm) | 13 |
Focal length (mm) | 4 |
Resolution (Full Cycle) -λ = 0.55um (um/lp) | 0.6 |
Depth of Field (mm) | 0.0019 |
Field of View - Ø24 eyepiece (mm) | 0.48 |
Mass (g) | 299 |
