5x M Plan Apo
- Sufficient working distance from 13 to 41 mm
- Infinity corrected
- Consistent 95 mm shoulder to object distance
- NA from 0.055 to 0.6 Standard thread adapter required for mounting
| Parameter | Value |
|---|---|
| Numerical Aperture | 0.14 |
| Working Distance (mm) | 41 |
| Focal length (mm) | 40 |
| Resolution (Full Cycle) -λ = 0.55um (um/lp) | 2.4 |
| Depth of Field (mm) | 0.029 |
| Field of View - Ø24 eyepiece (mm) | 4.8 |
| Mass (g) | 220 |
