Toshiba Teli BU132M
This BU series is an integrated-(one-body)-type camera that adopts all pixel data readout inter line CCD or CMOS. For video output and camera control, the USB3.1 Gen1 (USB3.0) interface standard is adopted for high transfer rate, and it is easy to integrate into industrial equipment.
Key Features
- High frame rate
- USB3.1 Gen1 (USB3.0) interface
- USB3 Vision Ver.1.0 conformity
- GenICam conformity Ver2.3
- IIDC2 Digital Camera Control Specification Ver.1.0.0
- e-CON Connector adoption
- Scalable
| Model Name | BU132M |
|---|---|
| Interface | USB 5Gbps (USB3.1 Gen1) (Only SuperSpeed is supported) |
| Pixels | 1.3M |
| Imager | CMOS image sensor |
| Imager model | EV76C560 |
| Resolution | 1,280(H) x 1,024(V) |
| Frame rate | 61fps (Mono 8bit) |
| Pixel size | 5.3μm x 5.3μm |
| Scanning area | 6.78mm(H) x 5.43mm(V) |
| Image size | 1/1.8 type |
| Aspect ratio | 5:4 |
| Scanning | Progressive |
| Electronic shutter method | MANUAL: Global shutter / Random Trigger Shutter: Global shutter |
| Random Trigger Shutter Type | External Trigger / Software Trigger |
| Random Trigger Shutter Mode | Edge / Level / Bulk (255 times) |
| Sequential Shutter | 16 entries (max) |
| Exposure Time | MANUAL: 30μs to 16s Random Trigger Shutter: 30μs to 16s (Edge or Bulk mode) |
| Synchronization System | Internal |
| Optical glass/filter | - |
| Sensitivity | 500 lx (F5.6, 1/62.5s) |
| Minimum illuminance | 2 lx (F1.4, Gain: +18dB, Video level: 50%) |
| Gain | MANUAL: 0 to +18dB |
| Black Level | -25% to +25% |
| Gamma / LUT | γ=1.0 to 0.45 / In 10bit, Out 10bit |
| Image Buffer | 256MB / 204 frames (all pixels readout) |
| Image Output Format | Mono 8bit / Mono 10bit |
| Readout Mode | All pixel, Scalable, Binning, Decimation, Mirroring, Flip |
| External trigger input | Low: 0 to 0.5V, High: 2 to 24.0V High active / Low active, Pulse width: 50μs (minimum) |
| Power supply | DC5V ±5% |
| Power consumption | 1.7W max. |
| Lens mount | C-mount |
| External dimension | 29(W) x 29(H) x 16(D) mm (Not including protruding parts) |
| Mass | approx. 33g |
| Operation temperature | 0°C to 40°C (below 50°C on cabinet surface) |
| Operation humidity | 10% to 90% (no condensation) |
| Conformity | CE, FCC, RoHS, WEEE, USB3 Vision, GenICam, IIDC2 |
